horizontal type ht graphitization furnace

type:induction furnace

input size:one control cabinet to one furnace and optional for one to two type or one to four type.

processed materials:380v±10%,50hz/60hz 3 phase 5 wire

applications:the equipment mainly used in the ht heating treatment on carbon material, carbon nano, carbon fiber, negative electrode materials, graphite powder, contacting terminal material and such related material.

  • overview
  • specifications
  • features

 applicable in high temperature graphitization treatment of thermal conductive material graphite film,new materials, carbon and carbon materials, special ceramics industry.

qq图片20170808084811

model

parameter

lab usage

production usage

nti-sml-54w

nti-sml-98w

nti-sml-182w

nti-sml-432w

nti-sml-576w

nti-sml-1280w

working size

mm

300×300×600

350×350×800

450×450×900

520×520×1600

600×600×1600

800×800×2000

heating type

/

if induction heating

control type

/

thyristor control or igbt control ( optional )

ht zone capacity

l

54

98

182

432

576

1280

loading weight

g

    ht zone capacity × density (g/cm³)×1000    remark:1l=1000cm³

ultimate vacuum

pa

20

if power

kw

150

200

250

350

500

700

max. working temperature

℃

3000

3000

3000

2900

2900

2900

usual working temperature

℃

2800

2800

2800

2800

2800

2800

temperature unifomity

℃

±10

±10

±10

±10

±15

±15

working environment

/

vacuum or ar, n2 atmosphere protection( micro positive pressure)

 feature:

1.the highest working temperature: 3000

2.double layer alumina as keeping temperature material, good the heat insulation and fire resistance effect, less heat loss and quickly heating.

3.equipping with high strength hard composite felt at the bottom of crucible, in order to ensure that the graphite crucible at high temperature level uniform force, it is 1.5 times the service life of similar products.

 4.unique design explosion-proof valve of furnace body safe and reliable.

the picture of furnace:

qq图片20170620085447

qq图片20170624091814



production procedure:


raw materials suitable for heating:

carbon material

packing mode:
