tungsten crucible vacuum hydrogen sintering furnace

type:laboratory furnace

  • overview
  • specifications
  • features

 vertical type hydrogen sintering furnace

1.application:

the equipment is batch type induction furnace, mainly used in tungsten carbide, silicon carbide, boron carbide, polysilicon material, calcium carbide, rare earth oxide, radiation proof material, gemstone,sapphire, metal, billets, powder metallurgy, rhenium material, vanadium carbide powder and such as metal powder and composite metal powder.

2.configuration:

380v±10%50hz/60hz 3 phase 5 wire

one control cabinet to one furnace and optional for one to two type or one to four type.


 3.technology parameter:

nti-sjl-4l

nti-sjl-9l

nti-sjl-57l

working size
l×w×h

mm

150×250

200×300

350×600

heating type

/

induction heating

power control

/

igbt or scr control

crucible

/

tungsten

max. capacity

l

4

9

57

loading capacity

g

ht area capacity × product’s density(g/cm³)×1000        1l=1000cm³

input voltage

/

380v±10%50hz/60hz   3 phase 5 wire

equipment structure

/

one power to one or two or four furnace

type

/

vertical

power

kw

50/90

60/120

90/150

frequency

hz

2500

2500

1500

max. temperature

2300

2300

2300

vacuum

pa

6.6x10-3

6.6x10-3

6.6x10-3

working tem.

2200

2200

2200

tem. uniformity

±10

±10

±10

working environment

/

vacuum or h2, arh2,n2  atmosphere environment (micro-positive pressure)

you can customize it as per your real requirement.

 we have lots of famous clients from the world like kolon in korea, usi in taiwan,

jiangxi zicheng in china, and joinset in korea and so on, as the below pictures showing.



clients visit.jpg



 honor of qualification




packing mode


 1.special size and requirement furnace can be customized.

2.the using method and operation and related knowledge taught by our engineer before shipment.

3.engineers available to service machinery overseas after-sales service provided.

4.payment terms:  t t.

5.price terms: fob shanghai port, china

6.transport way: by sea, we have good forwarders, super service and price !

7.delvery time: estimated time of delivery is 60 days after confirming to receive the deposit payment.

8.1 year of warranty.

9.other services: we can produce furnace according to your drawing design or requirements.
