refractory materials graphitization lab furnace

type:laboratory furnace

input size:custom made

applications:nt-cvd (g) series high temperature vacuum tube furnace specially designed for high temperature cvd craft, such as zno nanostructures with controllable growth, silicon nitride film plating, ceramic substrate electrical conductivity test, ceramic capacitors (mlcc) sintering atmosphere and so on.

  • overview
  • specifications
  • features

application :

the equipment mainly used in the ht heating treatment on carbon material, carbon nano, carbon fiber, negative electrode materials, graphite powder, contacting terminal material and such related material.

the furnace picture:


qq图片20170914093429

 all our furnace can be custom made:

nti-sml-4l

nti-sml-9l

nti-sml-57l

working size
l×w×h

mm

150×250

200×300

350×600

heating type

/

induction heating

power control

/

igbt or silicon controlled

max.capacity

l

4

9

57

loading capacity

g

ht area capacity×product’s density(g/cm³)×1000        1l=1000cm³

input voltage

/

380v±10%50hz/60hz   3 phase 5 wire

equipment structure

/

one power to one or two or four furnace

type

/

vertical

power

kw

80

100

150

frequency

hz

8000

8000

2500

max. temperature

3200

3200

2800

working tem.

3000

3000

2800

tem.uniformity

±10

±10

±10

working environment

/

vacuum or arn2  atmospher environment (micro-positive pressure)



feature:

the furnace adopts alumina fiber products insulation, keeping temperature, domestically produced high-quality silicon molybdenum bar heating, high quality corundum tube furnace, the system can pre-pumped vacuum and gas using rotameter control, importing single loop intelligent temperature control instrument control, the equipment has the characteristics of uniform temperature, stable control, fast heating speed, energy saving, high working temperature, long service life and so on, it is an ideal equipment for scientific research.

vertical type

the raw materials suitable for heating:




qq图片20170628142636

the packing mode:
