vertical type utral high temperature graphitizing furnace-凯发旗舰厅官网

graphitizing furnace is applicable in high temperature graphitization treatment of thermal conductive material graphite film,new materials, carbon and carbon materials, special ceramics industry.

[s]照片 002

model parameter		lab usage		production usage
model parameter		nti-sml-4l	nti-sml-9l	nti-sml-57l	nti-sml-100l	nti-sml-206l	nti-sml-339l	nti-sml-602l	ntg-sml-1177l
working size （d×h）	mm	φ150×250	φ200×300	φ350×600	φ400×800	φ500×1050	φ600×1200	φ800×1200	φ1000×1500
heating type	/	if induction heating
control type	/	thyristor control or igbt control ( optional )
ht zone capacity	l	4	9	57	100	206	339	602	1177
loading weight	g	ht zone capacity × density (g/cm³)×1000 remark：1l=1000cm³
ultimate vacuum	pa	20
if power	kw	80	100	150	200	250	350	600	800
max. working temperature	℃	3200	3200	3000	3000	3000	3000	3000	3000
usual working temperature	℃	3000	3000	2800	2800	2800	2800	2800	2800
temperature unifomity	℃	±10	±10	±10	±10	±10	±10	±10	±10
working environment	/	vacuum or ar, n2 atmosphere protection( micro positive pressure)

feature:

1.the highest working temperature: 3000℃

2.double layer alumina as keeping temperature material, good the heat insulation and fire resistance effect, less heat loss and quickly heating.

3.equipping with high strength hard composite felt at the bottom of crucible, in order to ensure that the graphite crucible at high temperature level uniform force, it is 1.5 times the service life of similar products.

4.unique design explosion-proof valve of furnace body safe and reliable.

configuration:

1.380v±10%，50hz/60hz 3 phase 5 wire

2.one control cabinet to one furnace and optional for one to two type or one to four type.

production procedure:

vertical type 2

raw material suitable for heating:

packing mode:
