metallurgy powder sintering furnace-凯发旗舰厅官网

  item      model

nti-sjl-4l

nti-sjl-9l

nti-sjl-57l

nti-sjl-100l

nti-sjl-206l

nti-sjl-339l

nti-sjl-753l

nti-sjl-2260l

working size
（l×w×h）

mm

150×250

200×300

350×600

400×800

500×1050

600×1200

800×1500

1200×2000

heating type

/

 intermediate frequency induction heating

power control

/

igbt or silicon controlled

max.capacity

l

4

9

57

100

206

339

753

2260

loading capacity

g

      ht area capacity×product’s density(g/cm³)×1000        1l=1000cm³

input voltage

/

 380v±10%，50hz/60hz   3 phase 5 wire

equipment stucture

/

one power to one or two or four furnace

furnace body type

/

                         vetical

power

kw

60

90

120

180

200

300

500

800

frequency

hz

8000

8000

2500

1500

1000

1000

1000

1000

max. temperature

℃

2500

2500

2500

2500

 configuration:

380v±10%，50hz/60hz 3 phase 5 wire

one control cabinet to one furnace and optional for one to two type or one to four type.

technical feature of vacuum sintering furnace:

1.adopting special furnace inner liner structure and heater arrangement, it has good uniformity of the furnace temperature.

2.adopting special structure for the degreasing chamber, efficiency sealing, completely degreasing and no pollution to the inner element.

3. vacuum sintering furnace has flexible vacuum pumping, vacuum sintering, micro positive pressure sintering, partial pressure sintering, micro positive degreasing, and other functions；

4. adopting the most advanced heat insulation structure and materials, good heat insulation performance of furnace liner, less heat, more than traditional design energy saving 25%.

5.adopting touch screen operation, plc centralized control, simple operation, high reliability.

6. vacuum sintering furnace has the alarm function of ultra-temperature and ultra-voltage, mechanical and automatic for pressure protection action, interlocking functions, high safety equipment.

7.vacuum sintering furnace has remote operation、remote fault diagnosis and remote software upgrades and other function.

8. the hard alloy products sintered by our vacuum sintering furnace can reach to 58hrc of hardness.

production procedure:

raw material suitable for heating:

packing mode:
