graphite film heat treatment carbonization furnace

type:resistance furnace

input size:custom made

processed materials:custom made

applications: for materials with high thermal conductivity (pi membrane) vacuum carbonization treatment

leave message

high thermal conductivity vacuum carbonization treatment is the key equipment to produce high performance

heat conductive film, the front door or double door in the front or back, pi membrane carbonizing by this

equipment, with excellent resistance structure and density. it can realize continuous vacuum

carbonization-sintering craft; equipped with decoking system, strengthen the decoking effect, furnace

atmosphere is more stable, easily control product quality, extending the service life of the carbon felt and the

heating material.

item / model		nti-thl-54w	nti-thl-243w	nti-thl-300w	nti-thl-400w	nti-thl-720w	nti-thl-(720-4000)w
working size （l×w×h）	mm	300×300×600	450×450×1200	500×500×1200	500×500×1600	600×600×2000	(600-1000)(600-1000)(2m-4m)
heating type	/	graphite rod heating(cage type)
max.capacity	l	54	240	300	400	720	720-4000
loading capacity	g	ht area capacity×product’s density(g/cm³)×1000 1l=1000cm³
input voltage	/	380v±10%，50hz/60hz 3 phase 5 wire
power	kw	50	105	120	135	189	300-500
heating zone	/	1	3	3	3	3	3-6
max.temperature	℃	1600	1600	1600	1600	1600	1600
working tem.	℃	1500	1500	1500	1500	1500	1500
tem.uniformity	℃	±5	±5	±5	±5	±5	±10
working environment	/	vacuum or ar、n₂atmospher environment (micro-positive pressure)
