st21-sk infrared thermometer

type：other related products

input size：167mm×ф50mm

leave message

st21-sk distance coefficient

outter size

installing bracket

adjustable installing bracket


water cooling jacket and air cleaner

model		st21-sk1	st21-sk2	st21-sk3
paramter	tem.range	600℃～1800℃	800℃～2500℃	1000℃～3000℃
	accuracy	value measuring ±1%
	repeatability	value measuring ±0.5%
	resolution	1℃
	emissivity	0.10～1.00 adjustable, step size 0.01
	response time	less than 50ms
	tem.meas.mode	instantaneous value, maximum value and average value
	time interval	1～30s, step size 1s
optics parameter	working band	1.0um
	distance coefficient	400:1
	aiming mode	telescope aiming
electrical	power	24v dc±10% 100ma
	output	4～20ma and rs485
environment	working tem.	-10℃～ 60℃, cooling with the water to 150℃
	storage tem.	-20℃～80℃
	relative humidity	10%～90%rh non condensing
physics	shell material	stainless steel
	size	167mm×ф50mm
	weight	600g
