main technical parameters:

output power: 20 ~ 3000kw

output frequency: ~ 100khz

maximum temperature: 1250℃(black metal) 2500℃(refractory metal)

output voltage: 20 ~ 2000v

the workpiece is heated material: steel, iron, copper, aluminum, stainless steel, tungsten, molybdenum, tantalum, niobium, etc.

shape of the workpiece is heated: a variety of shapes

feeding: automatic feed, manual feed

feeding continuity: intermittent film feeding section, a continuous feeding

feeding mode: automatic, manual

temperature measurement methods: infrared temperature measurement

cooling mode: water cooling loop, the outer loop water cooling

cimg0895

pict4380

sdc16685

workpiece diameter(mm)

φ10-50

φ50-100

φ100-150

φ150-1000

workpiece length

(mm)

100-500

200-600

500-1200

1000-2000

depth of the workpiece(mm)

0.2

1

2

5

main features:

l use for a variety of carbon, steel, iron bar heating.

l super audio heating φ50mm through the following bar more heat, more uniform , faster.

l ultra small size area ofonly 2 square meters can be moved easily with any forging, rolling equipment used in conjunction.

l installation, commissioning and operation of a school that will be very convenient.

l induction heating to the bar in a very short period of time heated to the desired temperature , greatly reducing the metal oxide material saving and improving both the quality of forging

l 24 hours a day working.

l automatic feeding.

l energy saving , environmental protection, reduce costs and manpower costs.

l facilitate the replacement of the sensor bar as a whole to adapt heating or heating of the different requirements of end.
