vertical type vacuum carbonization furnace

type:resistance furnace

input size:one control cabinet to one furnace and optional for one to two type or one to four type.

processed materials:380v±10%,50hz/60hz 3 phase 5 wire

applications:the equipment is batch type resistance furnace, mainly used in the heating treatment of pi film , titanium carbide, graphite and carbon material.

  • overview
  • specifications
  • features



application:
 application for thermally conductive film carbonization, glass-fiber carbonization, organic matter carbonization, powder carbonization and such as field, can be combined with the use of the graphite furnace, used in new materials, carbon and carbon materials, special ceramics industry.

the picture of carbonization furnace:

[s]img_20120426_100714





      model                parameter

lab usage

production usage

nti-thl-4l

nti-thl-9l

nti-thl-57l

nti-thl-100l

nti-thl-206l

nti-thl-339l

working size

mm

ø150*250

ø200*300

ø350*600

ø400*800

ø500*1050

ø600*1200

control process



thyristor control or igbt

heating type

/

resistance heating

ht zone capacity

l

4

9 57 100 206 339

loading weight

g

                 ht zone capacity × density (g/cm³)×1000   remark:1l=1000cm³

ultimate vacuum

pa

20

if power

kw

60

150

200 250 350 600

input power

/

380v,50/60hz



max. working temperature

℃

1600

1600

1600

1600

1600

1600

usual working temperature

℃

1500

1500

1500

1500

1500

1500

temperature unifomity

℃

±5

±5

±5

±5

±5

±10

working environment

/

vacuum or ar, n2 atmosphere protection( micro positive pressure)



feature

the carbonization process of the furnace is completed under the condition of inert gas, high precision temperature control, excellent uniformity of the furnace temperature inner, square cage type graphite rod, rod combination heating, convenient maintenance. square, circular boat are applicable, door front and behind can be both opened, it has good performance and stable quality, and is widely used in the cemented carbide industrial.

mmexport1490747405750

raw material suitable for heating:

carbon material


the packing mode:
