induction melting furnace

type:smelting furnace

applications:the products adopts intermediate frequency power of 500-4000hz supplying induction heating, its power range of 100-6000kw, suitable for melting steel, stainless steel and special steel, also used for melting cooper, aluminum, lead, zinc and other non-ferrous metal smelting.

  • overview
  • specifications
  • features

 intermediate  frequency induction melting furnace

●application
the products adopts intermediate frequency power of 500-4000hz supplying induction heating, its power range of 100-6000kw, suitable for melting steel, stainless steel and special steel, also used for melting cooper, aluminum, lead, zinc and other non-ferrous metal smelting.

the induction melting furnace:

qq图片20171027112339

qq图片20171027112239

qq图片20171027112243

(1)gwj series of intermediate frequency induction melting furnace without core:

rated capacity (t)
rated  power(kw)
rated frequency(hz)
input power
steel melting(1600℃)
iron melting(1450℃)
water consumption(kw.h/t)
melting rate(t/h)
electricity consumption(kw.h/t)
melting rate (t/h)
 power(kw.h/t)
0.15
120




1000




380v
50hz/60hz
0.15
820
0.16
780
5
0.25
200
0.25
800
0.26
770
6
0.35
250
0.35
800
0.37
770
6
0.5
350
0.5
760
0.53
680
8
0.75
500
0.74
615
0.81
585
10
1
500
0.76
789
0.79
750
10
1
750
1.05
690
1.1
680
15
1
1000
1.5
590
1.6
565
20
1.5
750
1.1
650
1.13
620
15
1.5
1000
1.5
600
1.53
570
20
1.5
1500








  500


660v
50hz/60hz
2.4
575
2.75
555
30
2
1000
1.54
630
1.58
610
20
2
1500
2.5
575
2.6
555
30
2
2000
3.0
570
3.15
550
45
3
1500
2.4
640
2.5
610
30
3
2000
2.9
610
3.05
590
45
3
2500
4.0
600
4.18
575
50
5
2500
4.05
570
4.16
555
50
5
3000

750v
50hz/60hz
5.00
560
5.20
545
60
5
3500
5.36
559
5.46
545
70
8
4000
5.40
569
5.90
557
80
8
5000
8.20
560
8.6
556
100
8
6000
10.2
560
10.8
555
120
10
5000
8.20
560
8.6
556
100
10
6000
10.6
560
10.9
555
120

(2)gwt series of intermediate frequency induction melting cooper furnace without core:

capacity(t)
power(kw)
input power
if voltage(v)
if frequency(khz)
working temperature(℃)
melting rate(t/h)
water consumption(t/h)
0.15
100
3φ380v50hz/or 60hz
750
1






    1250
0.16
2
0.30
160
0.31
5
0.50
250
0.52
8
1.00
500
1.16
10
1.50
750
1.69
15
2.0
1000
2.38
20
3.0
1500
3φ660v50hz/ or 60hz
1300
   0.5
3.21
30
5.0
3000
5.34
50

●feature

1.small volume, light weight, high efficiency and low power consumption;
2.low temperature around, smokeless, good working environment;

3.simple operation process, smelting operation reliability;
4. metal composition uniform, easy control of materials;
5.melting temperature rise fast, easy to control, high production efficiency;
6. high utilization rate of furnace, conveniently replacement.

the drawing of furnace:

the melting furnace component
